A4 - J&D TYPHOON 50", 42", 36", 30" & 24" | Slant Wall Exhaust Fan up to - 23,400 CFM Single Phase 115/230v & 3-Phase 208/230/460v, 3 Blade Cast Alum | VFS503CSCA-E (CLICK TO VIEW CUT SHEET & DETAILS) (CALL FOR FREE EXPERT ADVICE & PRICING),

(8 reviews) Write a Review
SKU:
VFS503CSCA-E
Weight:
250.00 LBS
  • Typhoon Slant Wall Exhaust Fan

The Typhoon slant wall exhaust fan has a heavy  gauge galvanized housing and X-frame motor mount to provide a solid  structure. Typhoon fans include an aluminum shutter with tie bar and  galvanized shutter clips to hold the shutter tight to the frame for less  vibration. With a quick twist of the clips, the shutter can be removed for  easy cleaning and maintenance. Typhoons are designed for exceptional  performance, low maintenance and low operating cost for your agricultural,  horticultural or industrial application. Call Factory Fans Direct at 888-849-1233 for Free Expert Advice and Discounts.
  • Typhoon Fans with Cones in Green Houses. Call Factory Fans Direct at 888-849-1233 for Free Expert Advice and Discounts.
  • Typhoon Fans with Cones in Green Houses. Call Factory Fans Direct at 888-849-1233 for Free Expert Advice and Discounts.
  • Typhoon Fans with No-Cones in Green Houses. Call Factory Fans Direct at 888-849-1233 for Free Expert Advice and Discounts.
  • Typhoon Fans with No-Cones in Green Houses. Call Factory Fans Direct at 888-849-1233 for Free Expert Advice and Discounts.
  • The following is a diagram of end wall to end wall ventilation.  Recommended  air flow is 60-120 Air Changes per Hour (ACH's).  Call Factory Fans Direct at 888-849-1233 for Free Expert Advice and discounts.
  • The following is a diagram of side wall to side wall ventilation.  Recommended  air flow is 60-120 Air Changes per Hour (ACH's).  Call Factory Fans Direct at 888-849-1233 for Free Expert Advice and discounts.
Complete line of Typhoon Exhaust Fans in sizes 24", 30", 36", 42" & 50", 5,180-23,400 CFM's and 115/230v & 208/230/460v. Call 888-849-1233 for Free Expert Advice, Cut Sheet & Factory Direct Pricing.

Description

TYPHOON - sizes 24", 30", 36", 42" & 50" Slant Wall Exhaust Fan - up to 23,400 CFM, Single and 3 Phase 3 Blade 115/230v & 208/230/460v

The Typhoon slant wall exhaust fan has a heavy gauge galvanized housing and X-frame motor mount to provide a solid structure. Typhoon fans include an aluminum shutter with tie bar and galvanized shutter clips to hold the shutter tight to the frame for less vibration. With a quick twist of the clips, the shutter can be removed for easy cleaning and maintenance. Typhoons are designed for exceptional performance, low maintenance and low operating cost for your agricultural, horticultural or industrial application. *When installing an exhaust fan, you must provide a proper inlet.   Call us today to help you choose the appropriate inlet and design an efficient ventilation system.

J&D Typhoon Cut/Data Sheet

Features on all of the Typhoon Fan Line:

Heavy duty 18 gauge galvanized housing. Smooth spun venturi to maximize airflow.
Rugged X-frame motor mount for stability and quiet operation.
No cone models include a 1" x 2" wire mesh guard that is hot dip galvanized after weld
Cone models include a hot dip galvanized safety cone guard
Additional 1/2" x 1" guard available to mount on the intake side to meet OSHA requirements
Ships fully assembled except shutter and/or cone
Plastic guard clips to reduce noise and vibration
3, 4, or 6 bladed galvanized propeller
50" models available with a 3 bladed cast aluminum prop with a Lifetime Warrenty
Spring belt tesioner on 48" and 50" belt drive models
Two speed motors available on select models (requires seperate speed control)
Shaft bearings are pre-lubricated, permanently sealed and rubber mounted with an eccentric locking double set screw collar for smooth operation.
Totally enclosed, maintenance free, high efficiency motors have completely sealed ball bearings and are covered by a Two Year Warranty.

Industrial/Commercial Exhaust Fans - Exhaust fans are an excellent way to expel or exhaust the air in a building or warehouse.

Factory Fans Direct offers a complete line of galvanized and fiberglass exhaust fans that are perfect for industrial or commercial applications, live stock barns, agricultural, horticultural, greenhouse and many more applications. We offer exhaust fans that range from a 10" ES Shutter Fan to the brand new 72" Mega Storm fiberglass exhaust fan.

Complete line of Typhoon Exhaust Fans are available in different sizes 24", 30", 36", 42" & 50", 5,180-23,400 CFM's and 115/230v & 208/230/460v motor voltage. Call 888-849-1233 for Free Expert Advice, Cut Sheet and Factory Direct Pricing.

Additional Information

How To Size Fan & Shutters System?

  1. First thing is to determine is the amount of air required. This is stated in CFM (Cubic Feet of Air per Minute). In addition, the required Air Changes Per Hour (ACH).  A Greenhouse requires 60-120 ACH's depending on location and weather conditions.
  2. The following formula to determine the CFM's and ACH's required for your greenhouse:
    CFM = Width x Length x Height
    Example: Greenhouse 12' wide X 40' long X 12' High requires 9,600 CFM at 60 ACH, 14,400 CFM at 90 ACH and 19,200 CFM at 120 ACH.
  3. Review the above table. Select the appropriate combination of fan(s) to achieve the necessary CFM rating and ACH. Be sure to match the total CFM output for your exhaust fan(s) to the CFM ratings for your Inlet Shutters. Below are examples of end wall to end wall and side wall to side wall ventilation. Call 888-849-1233 for Free Expert Advice.
 greenhouseventilation.jpg           sidewallwetwallandexhaustgreenhouse.png

Call 888-849-1233 for Free Expert Advice and Factory Direct Pricing.
